MIG STEEL SG2 welding wire diameter 0.8 mm
Spool Ø 200mm - Weight 5 kg

Excellent arc starting properties
For welding thicknesses from 1 to 6 mm
Requires shielding gas (Argon CO2 mix)
High arc stability at elevated currents
Good wire corrosion resistance
All-position welding
Polarity DC +

Applications:

General steel and ironwork applications
Railway construction
Shipbuilding

Standards:
AWS 5.18 : ER 70S-6
EN ISO 14341-A : G46 4 M21 3Si1 / G 42 3 C1 3Si1
DIN 8559 : SG2

TIG STAINLESS STEEL 316L filler rods
Diameter: 1.2 mm
Rod length: 1 meter
5 kg sleeve
5 kg is equivalent to +/- 565 rods
Requires the use of welding gas (pure Argon)

Ideal for direct current (DC) welding of austenitic stainless steels type 316L / 316 / 304 / 304L.
Standards: AWS A5.9- ER316L- EN 12072 - W19123L

Applications:

- Suitable for corrosive, acidic, chlorine environments
- Food grade
- Petrochemicals
- Handrails

High-performance automatic welding helmet. Sentinel A60 was designed with enhanced vision in mind.
Viewing area 40% larger than A50 (118 x 71 mm) for a wider view of your work.
Its new ADF offers excellent 1/1/1/1 EN optics from all angles
Ultra-clear True-Color lenses to reduce eye fatigue
Shade range from 3/5 to 13 adjustable in half-unit digital increments to optimise vision
4 overactive arc detection sensors for automatic brightness recognition in any work environment
Bright two-colour LED display for easy viewing in low-light conditions
New graphics to adjust sensitivity and delay time
Buttons carefully spaced apart from each other, easy to use even with gloves
ADF with nine programmable memory slots to save and quickly access welding profiles
Esab Sentinel A60 features an external grinding mode button for easy activation
New shade lock function to bypass the ADF and keep the helmet in its darkest state.
2 replaceable CR2450 lithium batteries with solar support
Internal warning indicators for grinding mode, low battery and ADF bypass lock
The signature flip-front design of the Sentinel A60 with infinite adjustment distributes weight
around the head.
Switching time (light to dark): 0.04 ms; switching time (dark to light): 0.1–0.9 s, adjustable

Approvals: CE: EN175, EN379, EN166; ANSI Z87.1; CSA Z94.3; AS/NZS 1337.1, 1338.1; TP TC 019/2011; ISO 16321-1/2

3-year warranty (battery excluded)

DELIVERED COMPLETE WITH 2 AMBER REPLACEMENT EXTERNAL PROTECTION LENSES, 2 CLEAR EXTERNAL PROTECTION LENSES, 2 INTERNAL PROTECTION LENSES AND A PRACTICAL PROTECTIVE CARRY BAG.

Refillable full gas cylinder pure Argon (99.99%)
Capacity: 8 Liters
Gas compressed at a pressure of 200 bar
Gas quantity: 1.5 m³
Height: 81.5
Diameter: approx. 13 cm
Weight: 13 kg

Warning: requires a flat-port regulator of type: 201002 / 245400.

Field of use:
For welding aluminum with a MIG welder (semi-automatic).
For welding steel, stainless steel, and aluminum in particular with a TIG welder.

The ESAB Rogue EMP 180 is a multi-process welding machine with INVERTER technology, designed to meet all your welding project needs, from light fabrication to repair and maintenance.
The system delivers industrial-grade arc performance and comprehensive controls that allow the welder to fine-tune arc characteristics according to the material being welded.
Weighing only 16.2 kg, with a 230 V single-phase power supply and compatibility with 10 kVA generators, this system offers maximum flexibility and portability, both in the workshop and in the field.

Its features

Large 14-segment display – instant readout of voltage and wire feed speed for clear visibility
- Synergic welding programs: easy adjustment of welding parameters for welds on material thicknesses from 0.5 to 8.0 mm
- Power Factor Correction (PFC) – ensures a stable arc, resistant to power fluctuations even when working with extension cables up to 100 m
- Unique robust industrial design with multiple lifting points and optimised cable management
- Arc Dynamics: Allows precise adjustment of arc characteristics to achieve a hard arc for carbon steel or a soft arc for stainless steel.
- Provision for torch with integrated spool; Rogue automatically configures when the torch is connected.
- IP23S protection rating for ideal use on job sites.

The Esab Rogue EM 180 comes with:

- 1 power cable 3 metres with Schuko 16 A plug,

- 1 MIG torch MXL 201 Euro 3 m,

- 1 earth cable kit 16 mm², 3 m,

- 1 gas hose with quick connector 4.5 m,

- 1 ESAB OK AristoRod mild steel/iron welding wire spool 12.50 0.8 mm 1 kg,

- 1 drive rollers 0.6/0.8 mm V (fitted), 0.8/1.0 mm V and 0.8/0.9 mm VK x flux-cored wire,

- safety instructions.

Why choose the Rogue ESAB ES 151i?
Two welding processes: MMA / Lift TIG
High duty cycle for a small unit: 97A@60% and 150A @25%
Compact and powerful: 10–150A single-phase (230V)
3-metre cable for power supply, electrode holder and earth clamp
Electrode diameter: 1.6 to 3.2 mm
Welds all Rutile, Basic, Stainless, Cast iron electrodes in DC
Generator compatible — IP23S
Ideal for maintenance services and the work of professional and passionate welders
3-year warranty

Delivered with:
1 electrode holder + 16 mm² cable 3 m long — 13 mm connector
1 earth clamp + 16 mm² cable 3 m long — 13 mm connector
1 shoulder strap for carrying the unit when working at height

Key features of the Kemppi Minarc Evo 150:
The little giant of MMA welding by Kemppi
Excellent welding and arc-striking quality
Automatic dynamic function
Compatible with long power cables
High duty cycle: 140A@35%
Lightweight and portable - 4kg
Generator compatible
Made in Finland
2-year warranty

This unit is delivered with:

1 electrode holder + cable (length 3m, cross-section 16 mm²)
1 earth clamp + cable (length 2m, cross-section 16 mm²)
1 power cable with plug, length 3m with Schuko plug

Duty cycle: 95A at 60% / 65A at 100%
Amperage range: 20 to 200A
Lift TIG function
Welds steel, cast iron and stainless steel up to 8mm thick
Compatible with rutile, stainless steel, cast iron and basic coated electrodes
Electrode diameter: 1.6 to 4 mm
Technologies: Hot Start, Arc Force
Power supply: 230 Volts 50/60 Hz – 16A –
Open circuit voltage: 84 V
Featherweight: 3.5 kg – 2-year warranty

Supplied with:
1x Cable with ground clamp (3 meters) (35/50 mm² connector)
1x Cable with electrode holder (3 meters) (35/50 mm² connector)
1x Power cable 1.5 meters

LCD control screen for easy and fast adjustment
MMA and TIG LIFT function
Welds coated electrodes: rutile, stainless steel, cast iron and basic between Ø1.6 and 2.5mm
On steel, cast iron and stainless steel up to 8 mm thick
Duty cycle: 60% - 70A
Inverter technology: immediate arc striking, smooth fusion and protection
Welding aids: Hot start, Arc force, Anti-stick
Power: 20-120A - 5 kVA
Open circuit voltage: 65V
Featherweight (2.5kg) - Dimensions: D26xH20xW11cm
Compact size and carrying handle

Warranty: 2 years

Delivered complete with:
- 1 Electrode holder + 12 mm² cable (1.6 meters)
- 1 Ground clamp + 12 mm² cable (1.4 meters)
- 1 220V single-phase power cable (1.5 meters)

Technological and robust
High duty cycle: 120A at 60% and 180A at 18%
MMA, MMA Pulse and TIG Lift process
Current range: 10 to 180A
Welds steel, cast iron and stainless steel up to 10mm thick
Compatible with rutile, stainless steel, cast iron and basic coated electrodes
Electrode diameter: 1.6 to 4 mm
Technologies: Hot Start, Arc Force, Antisticking, P400, ADS
Power supply: 230 Volts 50/60 Hz - 16A -
Open circuit voltage: 73 V
Weight: 4.9kg - 2-year warranty

Delivered in a case with:
1x Cable with ground clamp (1.6 meters) 16mm2 (10/25 mm2 connector)
1x Cable with electrode holder (2 meters) 16mm2 (10/25 mm2 connector)

Optional: TIG torch with valve - 4m - 10/25mm2 (044425)

Generator on wheels Welds steel, stainless steel and aluminium MIG duty cycle: 115A at 60% / 90A at 100% MMA duty cycle: 104A at 60% / 80A at 100% Amperage range: 30 to 200A Combines 3 welding processes in 1 product: - MIG/MAG with gas (steel/stainless wire Ø 0.6 to 1 mm and Alu 0.8 to 1mm) - MIG/MAG without gas (flux-cored wire Ø 0.9 mm) - MMA (basic and rutile electrode up to 4 mm) with Anti-stick function 4 rollers for Ø 200 mm (5 kg) or Ø 300 mm (15kg) spool Removable 250A MAG torch (2T/4T) 3m (8mm contact tip) Digital interface and very intuitive adjustment Compatible with 9kva generator Bottle support for gas cylinder up to 4m3 Single-phase 230 V - 16 A power supply Dimensions: 77 x 79x 47 cm - 32kg IP23 rating for outdoor use Accepts long extension cables (100m)

Delivered with: 1x 250A 3m torch - (MB25) 1x 2m 16mm² ground clamp 1x 2m 16mm² electrode holder 1x 1m20 gas hose

This Lincoln Speedtec 200C Inverter Synergic technology unit allows you to weld using 3 processes: MMA, MIG-MAG and TIG

It allows welding with rutile and basic electrodes (stainless steel – cast iron, etc.) of Ø 1.6 to 4 mm (electrode holder not included)

It is also possible to add a TIG welding torch as an option. In TIG mode, this unit cannot weld aluminium.

It operates on a standard 16 A – 230 V household outlet.

Its adjustment range is 20 to 200 A in MIG-MAG mode and 20 to 160 A in MMA or TIG mode
Easy polarity reversal to use flux-cored wire (gasless) of Ø 0.9 and 1.2 mm.

It features the following devices:

PFC (power factor corrector) It can be used with a 100 m extension cord without any loss of power.
The power supply can be provided from a generator.

HOT START adjustable, reduces the risk of sticking when the electrode and workpiece are cold, also facilitates arc striking and penetration.

ARC FORCE adjustable, maintaining constant amperage regardless of arc length.

ANTI-STICKING reduces the risk of the electrode sticking to the workpiece.

Its advantages:

The high duty cycle of this unit guarantees operation without premature triggering of the thermal protection system.

This unit is delivered with the sale with:
1 x 2 m power cable
1 x 2 m gas hose
1 x 3 m ground cable
1 set of Ø 0.8 and 1 mm drive rollers for steel welding wire


This tri-technology unit allows you, with a single machine, to weld in MMA, semi-automatic (MIG-MAG) and TIG modes.

MMA (electrode) and TIG welding solutions are available as options.

As standard, this semi-automatic unit features 17 programmed settings. The user simply needs to select the type of metal and the wire diameter. It is also possible to weld in manual mode by directly adjusting the settings parameters.

This welding unit uses wire on a spool. This welding process allows welding of thin materials (0.6 mm).

Very practical on thin sheets (automotive bodywork, chassis...), it avoids the weld bead restart that occurs when changing an electrode.

With the addition of a shielding gas, this unit enables welding on aluminium, stainless steel and steels in MIG-MAG and MMA mode, and steel, stainless steel and ferrous alloys in TIG mode.

Using a suitable wire of the CU Si3 type, it enables welding of HSS, EHS, UHS steels (automotive bodywork)

MIG welding with gas shielding requires the use of pure Argon gas for aluminium welding or an Argon + CO² mixture for steels and stainless steels.

Special case: For steel, it is possible to weld without gas when using flux-cored wire (which allows, for example, easier outdoor use). In this case, the thickness of the steel sheets must not be less than 1 mm to avoid the risk of burn-through.

This unit uses Ø 200 mm and 300 mm wire spools (flux-cored wire in 2 kg and other wires in 5 and 15 kg). An adapter for Ø 100 mm spools is available as an option.

Upon delivery, this unit includes:
1 Mig 180 A torch (3 metres)
1 earth clamp + 1.9 m cable.
1 roller for steel/stainless steel wire Ø 0.6 and 0.8 mm.
1 steel/stainless steel contact tip Ø 0.8 mm
1 gas hose for refillable cylinder

TIG welding with gas shielding requires the use of pure Argon gas for welding steels, stainless steels, ferrous alloys and copper...

As an option:

It is possible to add an electrode holder with a 3 m cable in order to weld with electrodes from Ø 1.6 mm to 4 mm.

Reference KIT000514

It is possible to add a TIG torch 4 m in length in order to weld in TIG mode using pure Argon shielding gas.

For connecting the unit to gas, it is recommended to use the 804208 fitting.

The ESAB Rogue EMP 180 is a multi-process welding machine with INVERTER technology, designed to meet all your welding project needs, from light fabrication to repair and maintenance.
The system delivers industrial-grade arc performance and comprehensive controls that allow the welder to fine-tune arc characteristics according to the material being welded.
Weighing only 16.2 kg, with a 230 V single-phase power supply and compatibility with 10 kVA generators, this system offers maximum flexibility and portability, both in the workshop and in the field.

Its features

Large 14-segment display – instant readout of voltage and wire feed speed for clear visibility
- Synergic welding programs: easy adjustment of welding parameters for welds on material thicknesses from 0.5 to 8.0 mm
- Power Factor Correction (PFC) – ensures a stable arc, resistant to power fluctuations even when working with extension cables up to 100 m
- Unique robust industrial design with multiple lifting points and optimised cable management
- Arc Dynamics: Allows precise adjustment of arc characteristics to achieve a hard arc for carbon steel or a soft arc for stainless steel.
- Provision for torch with integrated spool; Rogue automatically configures when the torch is connected.
- IP23S protection rating for ideal use on job sites.

The Esab Rogue EM 180 comes with:

- 1 power cable 3 metres with Schuko 16 A plug,

- 1 MIG torch MXL 201 Euro 3 m,

- 1 earth cable kit 16 mm², 3 m,

- 1 gas hose with quick connector 4.5 m,

- 1 ESAB OK AristoRod mild steel/iron welding wire spool 12.50 0.8 mm 1 kg,

- 1 drive rollers 0.6/0.8 mm V (fitted), 0.8/1.0 mm V and 0.8/0.9 mm VK x flux-cored wire,

- safety instructions.

Rogue ET181i is a DC HF-start TIG and MMA welding machine built with the latest inverter technologies to guarantee an extremely stable welding arc, ideal for working on steel, stainless steel, brass, cast iron...

The electronic boards of the Rogue ET181i are protected by a special coating that insulates them from moisture and dust (IP23S protection). The body is very robust and the dimensions are compact in order to allow the operator to transport and use this welding machine in a workshop or on a job site even in adverse environmental conditions.

The Rogue ET181i can generate a maximum welding current of 180 A and has a duty cycle of 116 A at 60%; these characteristics make this welding machine ideal for installation, maintenance and light metalwork.

The control panel of the Rogue ET181i is easy to use and the convenient LCD screen allows the operator to accurately view the welding parameters. From the control panel, it is possible to modify the TIG welding parameters to adapt the process to the needs the operator must face: LIFT or HF trigger mode, pre and post gas, initial and final current, up and down slope, 2T or 4T.

If you use the Rogue ET181i in MMA mode for MMA welding (electrode holder optional), it is possible to select the percentage of Arc-Force and hot start that best suits the welder's operating style; furthermore, from the control panel, it is possible to select the welding mode for CELLULOSE-coated electrodes.

The Rogue ET 181i comes with:

- Instruction manual
- Shoulder strap for transport
- ESAB SR26 TIG torch 4 metres with a grey Cerium tungsten electrode Ø 2.4 mm)
- Ground cable 16mm2 cross-section - length 3 m
- Gas hose with quick connector

This machine replaces the ESAB ROGUE ET180i model and additionally features the PULSE function compared to that previous model.

The Pulse function of the Rogue allows welders to better control heat input and arc stability. The controlled pulse action helps create a stable arc, avoiding excessive spatter and minimizing the risk of weld defects or the need for post-weld cleaning. The Rogue's Pulse technology facilitates penetration and fusion in the welding process, which is essential for creating strong and durable weld beads and for ensuring the structural integrity of manufactured components. Pulse technology helps minimize the heat-affected zone, thereby reducing the likelihood of material distortion or unforeseen metallurgical changes.

Ultra-compact and designed for craftsmen, the PROTIG 161 DC HF (160 A) delivers high-quality welds on mild and stainless steels thanks to its advanced secondary regulation. Its intuitive interface makes parameter adjustment straightforward.

OPTIMISED DC WELDING
Secondary regulation: ensures optimal arc stability and constant current in all positions.
TG DC: ensures quality welding on all ferrous materials such as steel, stainless steel, but also copper and its alloys…
TIG DC Pulsed: controls the temperature of the weld pool, limits distortion and thus allows the joining of thin sheets from 0.3 mm.
SPOT: fast and precise tacking before welding thin sheets.
2 ignition types: HF non-contact or LIFT contact for electrosensitive environments.
3 trigger modes: 2T, 4T and 4T LOG.
Automatic torch detection: compatible with blade and double-button torches

MMA WELDING
MMA: Basic and Rutile electrodes (up to Ø 4 mm)
Pulsed MMA: facilitates upward vertical position welding (pipes/pipeline…)
3 integrated welding aids:
- Antisticking: reduces the risk of electrode sticking upon contact with the workpiece
- Hot Start: facilitates arc ignition and is adjustable in seconds depending on the metal type
- Arc Force: temporary current increase in difficult welding situations.

INTUITIVE
Current and voltage display during and after welding (WPS/WPQR).
Memorisation of 10 programs per process for perfect reproducibility of your welds.
Intelligent fan management to reduce power consumption, dust intake and machine noise.

→ Supplied with:
1 TIG torch SR17 DB - 4 m, + accessories *
1 electrode holder and earth clamp with 25 mm² section cable, length 2 m.

* 1 electrode holder Ø 1.6 and 2.4 mm
1 diffuser for electrode Ø 1.6 and 2.4 mm
1 ceramic nozzle GR7 and GR5
1 long cap and 1 short cap

The PROTIG 200 AC/DC (200 A) is a versatile dual-process welding machine for TIG AC/DC and MMA (coated electrode) welding, in a compact and portable format. It allows joining all types of materials up to 4 mm thick (steel, stainless steel, aluminium, copper, magnesium or titanium). Its advanced secondary regulation ensures optimal arc stability and constant current in all positions.

5 TIG WELDING MODES

In DC mode
Standard DC: welding in direct current on the majority of ferrous materials.
Pulsed DC: limits heat build-up in the workpieces. Ideal for very thin sheet metal.

In AC mode
Pulsed AC: limits heat build-up in the workpieces. Ideal for very thin sheet metal.
AC Easy: simplifies use of the welding machine thanks to predefined parameters. The user only selects the diameter of their tungsten electrode on the interface.

OPTIMISED TIG SETTINGS
SPOT mode (TIG DC or AC): fast and precise tacking before welding thin sheet metal.
2 types of arc starting: HF contactless or LIFT by contact for electrically sensitive environments.
3 trigger modes: 2T, 4T and 4T LOG. Automatic torch detection: compatible with latching and dual-button torches.

MMA WELDING
MMA: Basic and Rutile electrodes (up to Ø 4 mm).
Pulsed MMA: facilitates vertical uphill welding (pipes/pipeline…).
3 integrated welding aids:
- Antisticking: reduces the risk of electrode sticking when in contact with the workpiece
- Adjustable Hot Start: facilitates arc striking and is adjusted in seconds according to the metal type
- Arc Force: momentary increase in current in difficult welding situations.

MAXIMUM PRODUCTIVITY
Memory for up to 30 programs per process.
Advanced menu for optimal welding control.
Current and voltage display during and after welding (DMOS/QMOS).
Reinforced casing with anti-shock pads.
Compact and easily movable on site.
Intelligent ventilation management to reduce power consumption, dust intake and machine noise.
Protected against overvoltages up to 400 V (PROTEC 400).

Delivered with:
1 TIG 26DB torch length 4 m, supplied with 1 Ø 1.6 electrode + 1 Ø 2.4 mm Cerium grey electrode (for stainless steel and steel welding) + A gas diffuser and an electrode holder for both tungsten electrode diameters + A GR5 ceramic nozzle and a GR7 ceramic nozzle
1 earth clamp + cable 25 mm² section length 2 m
1 electrode holder + cable 25 mm² section length 2 m

This ESAB Renegade ET 210iP is a single-phase professional TIG welding machine with high-frequency ignition and MMA, with IP23 protection rating, capable of being used even in the most demanding environments.

Thanks to its light weight, the various lifting points provided on the outer body and the high-quality shoulder strap, the Renegade ET 210Ip Advanced can be transported easily.

Renegade ET 210iP is equipped with an integrated active PFC circuit that allows it to be used even on a low-power network or if an extension lead is used (length up to 100 m).

Easy to use. It provides direct access to parameter settings and features a
simple and intuitive user interface that allows you to read the parameters, even from a distance.

It allows MMA welding of rutile, basic, stainless steel, cast iron electrodes... and also cellulosic ones.

Technical specifications:

- High robustness with IP23 protection rating, for use in workshops and on job sites, in demanding environments

- Pulsed TIG up to 999 Hz to increase control of heat input and weld pool

- Integrated PFC circuit for a stable arc even with an extra-long power supply cable, up to 100 m

- Intuitive panel, quick to configure, for greater precision and reduced downtime

- Dual functionality - Current mode trigger to switch between two output current levels to control
heat input and weld pool size

- Modular system to connect the cooling unit (optional) and the trolley (optional)
without tools

Examples of application sectors
Shipbuilding and offshore
Civil construction
Pipe manufacturing
Repair and maintenance
Heavy fabrication
Industrial and general fabrication
Mining
Steel formwork

Supplied with:
1 earth clamp + 25 mm² cable length 3 m - 13 mm connector
1 strap for carrying the machine on the shoulder when working at height + anchor points for lifting.
1 TIG torch SR-B 26 length 4 m
1 gas hose length 4 m

Electrode holder optional

The ASPECT® 200 AC/DC is equipped with advanced TIG AC/DC functions (4 waveforms, a pulsed mode, adjustable balance and offset), making it ideal for the most demanding TIG AC or DC welding applications.
It allows welding of materials up to 6 mm thick.

It offers a simple control panel with a bright digital display for easy visualisation and control of welding parameters.
2T and 4T mode selection
Innovative adjustment system via button control from the TIG torch.
Option to adjust via foot pedal or remote control
Spot mode.
Memory mode for saving your settings
Waveform selection.

Excellent electric arc performance = » Excellent ignition, fast and stable, minimum current 2A
Device "1 Phase Buck-boost Circuit" = » Low power consumption
» Bright digital display = Easy adjustment of all parameters
» Cooling unit and transport trolley = Easy transport on site » High robustness
» Encapsulated printed circuit board and "TRUE HD" manufacturing = High robustness
» Generator compatible = Ideal for outdoor job sites
» Advanced TIG AC/DC functions = 4 welding waveforms, Pulsed mode, adjustable Balance and Offset, simple control panel, self-adjustable AC current

To be used optimally and at its maximum capacity (200A) under intensive use, this unit must be paired with a cooling unit and a water-cooled torch.
The TIG setup can be converted to a water-cooled torch setup simply by adding a COOL ARC® 24 cooling unit.

In MMA mode, this unit features the following technologies:

Hot Start: Facilitates and speeds up arc ignition by providing a current surge to prevent electrode sticking.
Anti-sticking: Automatically reduces the output current in the event of a stuck electrode.
Arc Force: Temporary increase in welding current when the arc is too short.

This unit enables welding with tungsten electrodes (TIG welding) on steel, stainless steel, copper, nickel ...including aluminium .

It also allows continuous or Pulsed mode welding with rutile or basic electrodes (MMA welding kit optional).

It features the following functions:

TIG LIFT: Facilitates electrode striking.

TIG HF High-frequency contactless arc starting

TIG 2T/4T (manual or automatic welding)

TIG SPOT allows tack welding of parts before final welding.

HOT START adjustable: additional striking power in case of a difficult-to-strike electrode.

SLOPE DOWN adjustable: this system eliminates arc fade, thus preventing the formation of a crater at the end of the weld bead.

ARC FORCE: This process increases the amperage when the welding arc is kept short, which has the effect of increasing the penetration and mechanical strength of the weld bead.

ANTI STICKING: in the case of welding with coated electrodes, prevents electrode overload and thus preserves its characteristics,

TIG BI LEVEL: two different welding current parameters can be selected during the welding process, PRE-GAS/POST-GAS
( automatically adjusted by the microprocessor based on the current intensity and welding duration.

VRD: Improves safety during welding operations in damp environments

It also features the PULSE function, particularly suited for welding thin sheets where low heat input to the workpiece is required and adapted for welding in all positions.
When the pulse frequency increases, arc stability increases and therefore welding precision as well.
It also features the EASY PULSE system, allowing immediate pulsed mode welding even if the welder is not experienced in TIG welding, thanks to automatic parameter adjustment

THINSPOT function, enabling fast and precise spot welding.

For connecting the unit to the gas cylinder, it is recommended to use fitting 804208, which is positioned at the rear of the welding unit.

The Minarc TIG 200 EVO features high-frequency arc ignition, ensuring reliable performance across a wide variety of welding tasks.
Ideal for light construction, installation, repair and maintenance applications.

This unit features an LED display.
Precise arc ignition from 5A.
Duty cycle: 200 A @ 35%.
Pre-gas and post-gas adjustment
Compatible with generator use.

It is supplied with:
1 type 26 torch reference Kemppi TX 225, 8 m long - leather sleeve finish. Supplied with a GR6 gas nozzle, an electrode holder + gas diffuser and a grey cerium tungsten electrode Ø 2.4 mm
1 ground clamp + 25 mm² cable, 5 m long

This multi-process unit allows you to weld: MIG-MAG including flux-cored wire, MMA, and DC TIG

The sMIG ("smart MIG") function allows the system to "learn" and constantly adapt to the operator's welding technique to deliver a stable, reproducible arc

The innovative user interface with large TFT screen offers a clear view of welding parameters and settings

Unique industrial design with five-handle protection cage and monobloc steel structure housed in a light and highly mobile unit; full three-year warranty

Supplied ready to weld with the following consumables and accessories:

• ESAB MXL 200 MIG torch, 3 m
• M6 contact tip for 0.8 mm wire (qty 2)
• M6 contact tip for 1.0 mm wire (qty 2)
• Gas hose, 4.5 m, quick connector
• Electrode holder + 3 m cable
• Earth clamp + 3 m cable
• Steel wire spool Ø0.8 mm weighing 5 kg
• Reversible drive roll for 0.6/0.8 mm steel wire (installed in the drive system)
• Reversible drive roll for 0.8/1.0 mm steel wire
• 0.6 mm – 0.8 mm wire liner (installed in the MIG torch)
• 3 m power cable, fitted with plug
• Safety manual
• USB user manual

Optional: SR17 TIG torch

The ESAB Rogue EMP 210 PRO is a multi-process INVERTER technology welding machine designed to meet all your welding project needs, from light fabrication to repair and maintenance.
The system offers industrial-level arc performance and comprehensive controls that allow the welder to fine-tune arc characteristics to suit the material being welded.
Weighing only 16.7 kg, with a 230 V single-phase power supply and compatibility with 10 kVA generators, this system offers maximum flexibility and portability, both in the workshop and in the field.
True multi-process unit with Synergic MIG, Manual MIG, MIG brazing, flux-cored, Lift TIG and MMA (including 6010) processes
The 5.0" TFT screen is intuitive and clear, allowing the welder easy adjustment and a quick learning curve.
Synergic welding programs: complete range of welding parameters, 0.5 to 10.0 mm with a single control knob
Power Factor Correction (PFC): ensures a stable arc, resistant to mains voltage fluctuations, even when working with long extension cords up to 100 m
Unique robust industrial design: multiple handles for easy handling and cable management
Arc dynamics: precise adjustment of arc characteristics for a crisp / stable arc for carbon steel or a fluid / soft arc for stainless steel
Jobs: ability to save / recall up to 10 operations
Compliant with IP23S standard for indoor / outdoor use

Applications
Automotive construction
Automotive bodywork
Agricultural equipment
Civil engineering
Mechanical contractors
Repair and maintenance
Light fabrication

Package contents:
1 Multi-process welding machine 210 A with 3 m power cable and 16 A plug
1 MIG torch MXL 201, 3 m with Euro connector, with 1 contact tip for steel or stainless steel wire Ø 0.8 mm
1 Ground clamp with 3 m cable, OKC 35-50 16 mm2.
1 Electrode holder, Handy 200 A, heavy-duty 50 mm OKC, with 3 m cable.
1 Gas hose 4.5 m with quick connector.
1 Ø 200 mm spool of ESAB OK AristoRod steel wire 0.8 mm, weight 1 kg
1 Feed roller 0.6 / 0.8 mm (fitted on the machine) + 1 roller 0.8 / 1 mm for steel or stainless steel wire.
1 roller 0.8 / 0.9 mm for flux-cored wire
1 roller 1 / 1.2 mm for aluminum wire
1 nozzle for flux-cored wire (gasless) + 1 contact tip Ø 0.8 mm and 1 contact tip Ø 0.9 mm
1 user manual and safety instructions.

The Technomig 260 Dual Synergic is a welding machine (MIG-MAG / FLUX / BRAZING / MMA / TIG-Lift) of 250A.
It is easy to use thanks to One Touch technology.
With its versatility, Technomig 260 Dual Synergic allows operation on different thicknesses and various welded and braze-welded materials, making it the ideal tool for many fields of application, from maintenance to heavy steelwork and bodywork.

It is possible to manually adjust the arc length to modify the shape of the weld bead according to the operator's style and preferences

One Touch
Setting up the Technomig 260 Dual Synergic is simple and immediate: just program the material thickness and start welding. The 25 synergic curves provided for different gases and materials allow quality welds on steel, stainless steel, aluminium and galvanized sheet metal without wasting time on machine adjustments.

ATC
This process allows welding of thin thicknesses with great ease, reducing material distortion
Arc stability even at low currents.
Fast and precise spot welding
facilitates edge-to-edge sheet metal welding

Delivered with:
1 MIG-MAG torch 250 A length 3 m
1 reversible roller for steel/stainless wire Ø 0.6/0.8 mm
1 gas hose length 1 m
1 earth clamp + cable length 3 m

For connecting the machine to gas, it is recommended to use fitting 804208.

Welding and pickling with a single TIG machine
The Minarc T223 AC/DC is a brand new single-phase 220 A TIG AC/DC welding unit with an integrated electrolytic weld pickling process.

The Minarc T223 AC/DC includes standard and pulsed welding functions as well as memory channels and remote control options.
The adjustment controls are easy to use and the large, clear colour screen features a protective cover against impacts.

The new MAX Weldclean process is simple and quick to use.
Converting the TIG torch to pickling mode takes only a few moments. Your welds are clean, ready and perfect faster.

You weld, clean the welds with a low current and a cleaning solution, then neutralise with water.

The unit comes with:
- a TX225G torch with a length of 4 m
- A ground clamp + cable

This Inverter technology machine Lincoln Speedtec 180C allows you to weld using 2 processes: MMA-MIG-MAG

It allows welding with rutile and basic electrodes (stainless steel - cast iron, etc.) of Ø 1.6 to 4 mm (electrode holder not included)

It operates on a 16 A or 25 A - 230 V domestic outlet depending on the amperage setting.

Its adjustment range is 20 to 200 A for MIG-MAG welding and 20 to 160 A for MMA welding.
Easy polarity reversal to allow the use of flux-cored wire (gasless) of Ø 0.9 and 1.2 mm.

It features the following devices:

PFC (power factor corrector) It can be used with a 100 m extension cord without any power loss.
The power supply can be provided from a generator.

HOT START adjustable, which reduces the risk of sticking when the electrode and workpiece are cold, also facilitates arc ignition and penetration.

ARC FORCE adjustable, which maintains constant amperage regardless of arc length.

ANTI-STICKING reduces the risk of the electrode sticking to the workpiece.

Its advantages:

The high duty cycle of this machine guarantees use without premature triggering of the thermal protection system.

This machine is delivered with:
1 power cable 2 m
1 gas hose 2 m
1 ground cable 3 m
1 set of rollers Ø 0.8 and 1 mm for steel welding wire


Welds steel, stainless steel and aluminum from 0.6 to 6mm in all positions
MIG duty cycle: 130A at 60% / 110A at 100%
MMA duty cycle: 110A at 60% / 90A at 100%
TIG duty cycle: 135A at 60% / 115A at 100%
Current range: 20 to 200A - Voltage: 76V
Combines 4 welding processes in 1 product:
- MIG/MAG with gas (steel/stainless steel wire Ø 0.6/0.8 to 1.6 mm and aluminum 0.8 to 1.6mm)
- MIG/MAG without gas (flux-cored wire Ø 0.9 to 1.2 mm)
- DC TIG Lift - Lift arc ignition
- MMA (basic and rutile electrode up to 5 mm)
4 drive rolls for spool Ø 200 mm (5 kg) or Ø 300 mm (15kg)
Removable STEEL MIG torch 250A 3m (8mm contact tip)
Digital interface and highly intuitive settings
Compatible with 9 kVA generator and 100m extension cord
Single-phase power supply 230 V - 16 A
Dimensions: 27.5 x 55 x 44 cm - 20kg
IP21 rating

Supplied with:
1x 250 A 3m torch MB25
1x 200A 2.5m ground cable
1x MMA electrode holder 2m
1x User manual
2x 0.8/1mm drive rolls

TIG torch optional

Suitable for maintenance and bodywork, the EASYCUT 40 plasma cutter easily cuts all types of metal up to 15 mm thick. With a power output of 40 A, it excels at precision cutting at low amperage.

Inverter technology ensuring quality cutting on all steels (mild, stainless, hardened, HLE), aluminium, copper, etc.
Easy and quick consumable installation (Trafimet® standard).

Efficient cutting: air-cooled torch body providing high arc stability at various operating levels.
Easy-to-use trigger mechanism for greater comfort. Designed to withstand shocks and heat.
Quick torch connection/disconnection, no tools required.

Manual air pressure adjustment (2.5 < 6.5 bar) with front panel bargraph.
Automatic torch detection.
HF-free ignition to avoid interference that could damage nearby electronic equipment.

Protected against overvoltage and overcurrent
Torch presence or insufficient air pressure indicator.

→ Requires connection to a compressed air supply delivering 100 l/minute at a variable pressure between 2.5 and 6.5 bar depending on the machine setting.

Supplied with a TPT 40 torch 4 m long and a 10 mm² section earth clamp cable 2 m long.

This inverter technology plasma cutter with contact pilot arc ignition allows you to cut without deformation all conductive materials such as steel, stainless steel, galvanised steel, aluminium, copper, brass
It is compact and has a small footprint (450 x 182 x H 292 mm) and weight (7 kg)
This cutter enables clean cutting of materials up to 12 mm thick or 15 mm in separation.
It allows sheet metal piercing (see the user manual for this purpose) for supports with a maximum thickness of 4 mm
Consumable change indicator device

This cutter is fitted with a warning indicator light for consumable replacement

Delivered with a 4 m torch + ground clamp and cable 3 m long

The Tomahawk 30 K plasma cutter is the most flexible plasma cutting machine on the market. The machines are delivered ready to use, capable of cutting quickly and precisely.
Powered by single-phase 230V, ideal for on-site work. With this cutter, plasma cutting will no longer be a problem — forget grinding, simply take the torch and cut in just a few seconds.

• High performance - Innovative electrode and cutting nozzle design.
• Flexible - a single-phase 230V power supply is sufficient.
• Robust - long-life integrated compressor or external compressed air supply.
• Portable 18.5 kg only, small and compact.
• Cutting of various metals – Unalloyed steel, stainless steel, aluminum and others.

Output current range 15 - 30 A
Duty cycle 30A@60% - 25A@100%

Example of possible cutting thickness for steel:
Recommended cutting thickness: 12 mm
Clean cutting thickness: 16 mm maximum
Separation cutting thickness: 20 mm maximum

thanks to a button on the front of the unit, it can be connected to a compressor.

Delivered with
One LC 30 manual torch, length 4 m - EURO connector
Cable and ground clamp

High-performance plasma cutting.

The Lincoln Electric Tomahawk plasma cutting system focuses on three elements:

• S (Starting) - An innovative and patented arc starting system that preserves and extends electrode service life.
• P (Performance) - Thanks to a very high-speed helical airflow combined with a special electrode and nozzles designed to concentrate the plasma flow.
• L (Lifetime) - The optimized airflow cools the electrode and nozzle for extended service life.

• Performance - Innovative cutting electrode and nozzle design.
• Service life - The innovative design increases consumable service life.
• Flexible - Multiple torch configurations.
• Concentrated plasma flow - Low heat input, less distortion.
• Cutting of different metals – Mild steel, stainless steel, aluminum and others.

Main Specifications

• advanced arc starting technology, without High Frequency (HF)
• innovative electrode and nozzles
• Improved consumable service life
• Reduced heat input, less distortion
• Multiple torch configurations

 Clean cut thickness 40 mm.
Severance cut thickness 45 mm.

Included accessories:
Power cable (3 m)
LC 105 manual torch (7.5 m)
Ground cable and clamp set (6 m)
Air connection kit
Torch consumables parts kit

Your compressor must provide an airflow of 180 liters per minute at a pressure of 5 bar for proper operation of this cutter.

The Cutmaster 30+ combines power and portability, offering a high-performance solution for plasma cutting. Its 4.3" TFT LCD screen and enhanced features ensure precise control and increased flexibility for clean cuts up to 10 mm. Equipped with the SL60 1Torch, you get the complete plasma cutting package.

Recommended piercing and cutting capacity: 10 mm

Maximum edge cutting capacity: 16 mm

Key features:

Portable welding machine with electric transformer
Ideal for home users and maintenance work
Designed for assembling, repairing sheet metal or steel sections
Setting assistance via the SMART table
Duty cycle: 85A@6% - 40°C
Current range: 40 to 110A
Welding NO GAS only for flux-cored wire Ø 0.6 to 0.9 mm
2-roller wire feeder for Ø100 mm spool (1 kg)
Fixed torch 150A 2.2m (0.9mm contact tip)
Single-phase power supply 230 V - 16 A
Dimensions: 34 x 17 x 34 cm - 23.3kg

Supplied with:
- 1 earth clamp (cable 1.6 m / 16 mm²)

Adaptive tool for the mobile welder
Excellent welding quality and precise arc striking
High duty cycle: 220A@ 20% - 160A@60% - 120A @ 100%
Uses Ø 100 mm (1 kg) or Ø 200 mm (5 kg) wire spools
Generator compatible
3-metre torch
Lightweight and portable
LCD control panel
IP23 rating for outdoor use
Dimensions: 450x227x368mm - Weight 14.2kg
2-year warranty

Delivered with:

1 torch 3 m long with ergonomic handle, fitted with a contact tip for steel or stainless steel wire Ø 0.8 mm
1 reversible roller for stainless steel or steel wire Ø 0.8/1 mm
1 earth clamp + cable 16mm² cross-section, 2.50 m long
1 gas hose 5 m long


Ultra-compact and designed for craftsmen, the PROTIG 161 DC HF (160 A) delivers high-quality welds on mild and stainless steels thanks to its advanced secondary regulation. Its intuitive interface makes parameter adjustment straightforward.

OPTIMISED DC WELDING
Secondary regulation: ensures optimal arc stability and constant current in all positions.
TG DC: ensures quality welding on all ferrous materials such as steel, stainless steel, but also copper and its alloys…
TIG DC Pulsed: controls the temperature of the weld pool, limits distortion and thus allows the joining of thin sheets from 0.3 mm.
SPOT: fast and precise tacking before welding thin sheets.
2 ignition types: HF non-contact or LIFT contact for electrosensitive environments.
3 trigger modes: 2T, 4T and 4T LOG.
Automatic torch detection: compatible with blade and double-button torches

MMA WELDING
MMA: Basic and Rutile electrodes (up to Ø 4 mm)
Pulsed MMA: facilitates upward vertical position welding (pipes/pipeline…)
3 integrated welding aids:
- Antisticking: reduces the risk of electrode sticking upon contact with the workpiece
- Hot Start: facilitates arc ignition and is adjustable in seconds depending on the metal type
- Arc Force: temporary current increase in difficult welding situations.

INTUITIVE
Current and voltage display during and after welding (WPS/WPQR).
Memorisation of 10 programs per process for perfect reproducibility of your welds.
Intelligent fan management to reduce power consumption, dust intake and machine noise.

→ Supplied with:
1 TIG torch SR17 DB - 4 m, + accessories *
1 electrode holder and earth clamp with 25 mm² section cable, length 2 m.

* 1 electrode holder Ø 1.6 and 2.4 mm
1 diffuser for electrode Ø 1.6 and 2.4 mm
1 ceramic nozzle GR7 and GR5
1 long cap and 1 short cap

LCD WELDING MASK

Essential for safety, the GYSMATIC TRUE COLOR XXL optoelectronic welding helmet protects the welder's face and eyes from UV, infrared and spatter. Fully automatic, the mask switches from the clear state to the tinted state in a fraction of a second, from the moment the arc is struck. Supplied with a headband, it frees the welder's hands and provides all the comfort needed for welding work.

UV/IR protection level: DIN 15
Shade: adjustable from 5 to 13 - True Color Technology
Classification: 1/1/1/1
Viewing area: 100 x 83 mm
Reaction time: 0.10 ms
Settings: sensitivity, shade, delay, memory
Power supply: solar + 2 CR 2450 batteries
Weight: 680 g
Standards: EN 175 / EN 379

Applications
MMA: 5 to 400 A
TIG: 2 to 250 A
MIG/MAG: 5 to 400 A
Grinding mode (Grind)

Consumables:

Outer lens 114 x 133 mm (reference 043893)
Inner lens 106 x 89.5 mm (reference 046825)

This pack includes
1 Lincoln multi-process welder SPEEDTEC 200C
1 MIG-MAG torch 3 m long LGS 250
1 Refillable gas cylinder for steel welding, capacity 2.3 m3
1 Two-gauge regulator Le Lorrain

This pack contains: - Speedtec 180 C K14098-1 welding machine - W10430-25 torch - Two-gauge regulator 094200 - F11885M trolley - Rechargeable Argon/CO2 Enermix C15 cylinder

This pack contains: - 1 leather apron with pocket - GA1049BST - 1 pair of Lucifer long-cuff gloves G100501 Save 10% with this offer!

Inverter electrode welding machine, MMA
Power: 180A
Easy: Automatic adjustment via LCD screen
Versatile: For electrodes from 1.6 to 4 mm
Versatile: Easy to use with rutile, basic, stainless steel, cast iron electrodes, etc.
Technologies: Hot start, Arc force, Anti Stick

Welding machine delivered in a box with:
1x Cable with earth clamp (3 metres) 16 mm² – 16/25 connector
1x Cable with electrode holder (3 metres) 16 mm² – 16/25 connector
1x User manual
2-year warranty

This pack contains:

x 1 ELITE XXL TRUE COLOR welder's mask - ref 202514
x 1 Multi-purpose split leather apron - ref GA1048BST
x 1 Multi-purpose split leather gloves - ref G100501
x 1 kg rutile steel electrodes - D2.5 - ref E6013251
x 1 kg rutile steel electrodes - D3.2 - ref E6013321
X 1 Hammer/brush - 2 rows - Sacit - Ref CAV000081
